How to select flowmeter for measuring steam

How to choose the flowmeter for measuring steam? The steam flowmeter is used in crude oil, chemical plant, metallurgical industry, pharmaceutical industry, electric power engineering, papermaking industry and other manufacturing industries to measure and verify the total flow of steam.Steam flowmeter has many types of instruments to choose, how to choose the actual application to follow the detailed analysis of the selection, the following brief talk about: how to measure steam flowmeter selection.

How to select flowmeter for measuring steam

Rotor type steam flowmeter: this type of steam flowmeter is relative to other steam flow calculation traditional type, its working pressure regulation is manual type, its construction is durable, the measurement is smooth, suitable for the measurement of saturated water vapor and slightly superheated steam.Its application caliber is generally in the middle of DN(50 ~ 150).

The actual selection should be based on the application manufacturer to show a series of main parameters (such as pipeline working pressure, pipeline diameter, measurement of application temperature, etc.), the total flow category, the selection of orifice size steam flowmeter (each diameter often large, medium, small three orifice).

Intelligent vortex type steam flowmeter: excellent in traditional steam flowmeter, it chooses the credibility heat meter, the application of integrated manufacturing sensing technology components and control circuit, its no molecular thermal motion sensing technology part, drive part is to choose the high quality of auto relay, to further improve its reliable performance.

The characteristics of intelligent vortex street steam flowmeter are small working pressure damage, large measuring range and high precision.In the selection is the customer must show the main parameters of measuring load, such as pipe diameter, pressure, working temperature, installation method, etc. (the meter is divided into clamping type and flange type).The key application work pressure damage small place.

Throttling device (orifice plate type) flowmeter: this flowmeter has a long history, and the two kinds of flowmeters are derived from the basic principle of orifice plate flowmeter.In addition to the standard orifice, there are also curved tube flowmeter, nozzle flowmeter, long nozzle flowmeter and ring orifice flowmeter, which can be used as steam flowmeter.

Throttling device (orifice plate type) flowmeter has many kinds, large caliber, and can be selected in a wide range.If as steam flowmeter selection when, must be more clients manufacturers to produce a large number of accurate load main parameters, such as the application of pipe diameter, pressure, temperature, pressure, temperature), can according to the mobile phone software to accurately measure the size of the orifice plate, the subsequent one-on-one manufacturing measuring steam orifice plate flowmeter.
