Shanghai JSN Micro Flow Meter CO.,LTD has a completeplanning, design, research and development, manufacturing, sales, servicesystem, is committed to providing high-quality,high-performance micro flowmeters,ovalgear flow meter ,electromagnetic flow meter,mass flow meter,piston flowmeter,gear flow meter,gear pump,gear metering pump for professional channelcustomers and end customers at home and abroad. Since the 1980s, it has reliedon a strong technical R&D team to focus on the field of flow meter measurement,and developed ultra-miniature, high-precision, high-frequency, high-pressure,and large-scale flow metering equipment. Today, there are more than 500,000units (sets) products are serving all corners of the country and are widelyused in polyurethane, dispensing, hydraulic, odor, petrochemical, power,military, aerospace, scientific research, nuclear industry, cement, metallurgy,steel and other industries.



surfactant oval flow measurement

At presentdomestic Oval gear flow meter structure is complex, bulky, bulky, noisy, smallscale, not suitable for low viscosity liquid, the market is more common withDTO series and OGM series. For these problems the country has been unable toovercome, while the Shanghai JiShen instrument Instrument company oval gear Ovalgear flow meter does not have the above problems, such as the same DN25caliber, our model CX-M25-AL, flow range: 0.5 ~ 100L / M, range of 1: 200 orhigher, and weighs only 1.5KG , While the DTO-25, the flow of 600-6000L / H,range ratio of only 1:10, the weight of up to 23KG. All this due totechnological breakthroughs, our chief engineer Tu workers, he is a formerSiemens senior engineer, the use of equipment It is also Siemens CNC MachiningCenter with cutting accuracy up to 0.001mm, which ensures that we produce highquality flow meters.

Base deep gear wheel flowmeter on the production of all caliberflowmeters, basically have stock inventory, which in itself shows that thecompany"s funds and sales are good, we dare to do inventory. Hee Oval gear flowmeter has two national inventions, In the process of production qualitycontrol, starting from the beginning of the procurement of raw materials, everyproduction and precision machining links careful examination, each of the Ovalgear flow meter factory must be continuous calibration test. Processinstallation ISO9001 quality management system strictly enforced, the producthas the CE, SGS and other EU certification. Our company has "the qualityof Germany, China"s manufacturing" as the slogan to create a world-classoval gear flow, real automation instrumentation industry Benchmarking business.



surfactant oval flow measurement

The Ovalgear flow meter is a volumetric flow meter that consists of a flow chamber in achamber and one or several elements that are rotated by fluid flow to form aflow meter. Leakage between the rotating element and the inner wall and theselected working range The internal flow rate is negligible. The rotation ofthe element is transmitted mechanically or by other means to the indicatingdevice to indicate the volume flow of the fluid flowing through.



surfactant oval flow measurement

Technicaldata of Gear type flow meter

Model	K-factor	Minimum  flow	Flow  range	Accuracy
G0.025	0.025ml	0.001L/Min	0.008~2L/Min	0.5%
G0.04	0.04ml	0.004L/Min	0.2~4  L/min	0.5%
G0.1	0.4ml	0.008L/Min	0.01~8L/min	0.5%
G0.2	0.245ml	0.01L/Min	0.16~16  L/min	0.5%
G0.4	0.4ml	0.01L/Min	0.16~16  L/min	0.5%
G1	1.036ml	0.02L/Min	0.4~80  L/min	0.5%

What are the precautions for the gear flow meter?

1) In the field installation, it should be noted that the direction of the arrow on the flow meter housing is consistent with the flow direction of the fluid;

2) The flowmeter is installed on the same pipe with the same nominal internal diameter as the inlet and outlet fittings. When the pipe is connected with the flowmeter, the seal should not protrude into the fluid;

3) The fluid to be measured shall be filled with the metering room of the flowmeter and the connecting pipes before and after it. If the fluid to be measured contains gas, a gas separator shall be installed before the flowmeter and the filter;
